Solar Off-Grid Inverter
Product Introduction
Product Model: 33224KW(4KVA)
Volt Input Power: 5000W
Mppt Tracks Voltage Range: 40VDC-450VDC
Rated Input Voltage: 360VDC
Pv Input Voltage Voc: 450VDC
Maximum Photovoltaic Input Current: 18A
Mppt Track Number: Route 1
Rated Battery Voltage: 24VDC
Battery Voltage Range: 21~30VDC
Photovoltaic Charging Current: 120A
Mains Charging Current: 80A
Product Features
1、High frequency design, high power density, small size, high efficiency
2、Two-way energy storage design, can realize the two-way flow control of electric energy, photovoltaic and mains can charge the battery
3、Ultra-wide MPPT range, up to 40Vdc(24V model)/80Vdc (48V model)
4、The working mode can be set (grid-connected mode, off-grid mode, mixed mode)
5、With grid-connected current setting function
6、Output priority setting function
7、With charging priority setting function
8、With lithium battery BMS communication function
9、Support battery-free operation mode
Technical Parameters
Product Application
This product can be used inResidential,Household appliance,office,Telecom,Network Equipment,Power station
